SHOTOVER F1

SHOTOVER F1 Recalibrating Versatility

The SHOTOVER F1 adapts to your style, from broadcast to features.

A 6 axis gyro stabilized platform delivers unshakable stability with look down capability for use inverted, or right side up on almost anything that moves.

It rigs fast and accommodates a wide range of cameras and lenses, including the Arri Alexa M, Red Epic, Canon C500 and Sony F55 & HDC-2500, for the look you want.

While its compact carbon fiber construction means it ships as excess baggage on commercial flights worldwide with no export restrictions.

SHOTOVER F1 System Features

  • Quickly and easily interchange multiple cameras and lenses
  • Compact size and weight allows affordable transport as freight or excess baggage
  • No ITAR restrictions or EAR licensing requirements
  • Compatible with most FAA and EASA approved aircraft mounts
  • Easily integrated onto a wide variety of mounting platforms
  • 6-axis gyro stabilized with look down capability
  • Windowless operation option for brilliant imagery without reflections
  • Fiber optic video data transfer for clean 3GHz imagery
  • State of the art electronics and design techniques deliver unshakable stability and ultimate functionality
  • Customizable graphics overlay for real time operator feedback
  • Auto or Steerable horizon with the most advanced steering capabilities on the market
  • Inverted operation using auto-position detectors
  • Remote controlled polarized filter rotation, rain deflector and other accessories available

SHOTOVER F1 Specifications

STABILIZATION

  • 6-axis with no gimbal lock
  • High performance non-ITAR sensors
  • Distributed Multi-processor closed loop servo control system
  • Proprietary gimbal control algorithms

GIMBAL FIELD OF VIEW

  • Pan: 360 degrees continuous (via electrical and optical rotary joints)
  • Tilt: +45 to -140 degrees
  • Roll: +/-85 degrees (steerable or auto horizon)
  • Max slew rate: 100 deg/sec

DATA / COMMUNICATION

  • Fiber Optic lines
  • CAN Bus
  • RS 422 Serial Bus
  • Ethernet

WEIGHT

  • Turret with max payload less than 59kg (130lbs)
  • Operator control unit 2.7kg (6lbs)
  • Junction control box 4kg (9lbs)
  • External cable set: 2.5kg (5.5lbs)

POWER

  • 19-72 VDC
  • 12 Amps Max Draw (at 28V)

ENVIRONMENTAL

  • Operating Temperature: -20 to +50 degrees C

OPERATOR CONTROL UNIT

  • Lightweight
  • Customizable video overlay (Monitor Output)
  • Recess for camera remotes such as: Sony RM-B750, Arri RCU-4
  • Other control layouts available upon request

CAMERA AND LENS COMBINATIONS

CANON C500

  • Canon 30-300
  • Canon 14.5-60
  • Angenieux Optimo 17-80
  • Angenieux 25-250 HR
  • Angenieux 25-250 DP
  • Arri/ Fujinon Alura 18-80
  • Fujinon Premier 18-85
  • Fujinon Premier 14.5-45

Red Epic X / Dragon / Weapon

  • Canon 30-300
  • Canon 14.5-60
  • Angenieux Optimo 15-40
  • Angenieux Optimo 28-76
  • Angenieux Optimo 17-80
  • Angenieux 25-250 HR
  • Angenieux 25-250 DP
  • Arri Fujinon Alura 18-80
  • Fujinon Premier 18-85
  • Fujinon Premier 14.5-45
  • Fujinon Cabrio 19-90
  • Fujinon Cabrio 85-300
  • Fujinon 42×9.7
  • Zeiss 14mm Master Prime
  • Zeiss 16mm Master Prime

Sony F55 without Recorder

  • Canon 30-300
  • Canon 14.5-60
  • Angenieux Optimo 15-40
  • Angenieux Optimo 28-76
  • Angenieux Optimo 17-80
  • Angenieux 25-250 HR
  • Angenieux 25-250 DP
  • Arri Fujinon Alura 18-80
  • Fujinon Premier 14.5-45
  • Fujinon Cabrio 19-90
  • Fujinon Cabrio 85-300
  • Zeiss 14mm Master Prime
  • Zeiss 16mm Master Prime

Sony F55 with Recorder

  • Angenieux Optimo 15-40
  • Angenieux Optimo 28-76
  • Fujinon Cabrio 19-90
  • Fujinon Cabrio 85-300
  • Zeiss 14mm Master Prime
  • Zeiss 16mm Master Prime

Sony HDC 2500

  • Fujinon HA 42×13.5
  • Fujinon HA 42×9.7

Alexa M-Single Fibre / Alexa Mini

  • Canon 30-300
  • Canon 14.5-60
  • Angenieux Optimo 15-40
  • Angenieux Optimo 28-76
  • Angenieux Optimo 17-80
  • Angenieux 25-250 HR
  • Angenieux 25-250 DP
  • Arri Fujinon Alura 18-80
  • Fujinon 18-85 mm T2
  • Fujinon Premier 14.5-45
  • Fujinon Cabrio 19-90
  • Fujinon Cabrio 85-300
  • Zeiss 14mm Master Prime
  • Zeiss 16mm Master Prime

OPTIONS

  • Geo referenced overlay
  • Integrates with third party geo mapping
  • Remote controlled rotating polarizer
  • Rain deflector
